The Motivity Ceiling of Tense with a diameter of only 17,5 mm is the smallest KNX motion detector in the Tense range. The black or white plastic rosette can be cut off for a minimalistic end result.
The KNX Motivity Ceiling Black contains a motion detector and a temperature sensor, while the KNX Motivity Ceiling White also has the ability to monitor brightness.
POWER SUPPLY: min 21 V DC max 31 V DC supplied by the KNX bus line
MAX POWER CONSUMPTION: 240 mW
CONNECTION TO THE BUS: pluggable terminal
OPERATING TEMPERATURES: -5°C to +45°C
MAX HUMIDITY: 93% relative humidity, no moisture condensation
TYPE OF PROTECTION (EN 60529): IP20 (installed in ceiling)
DIMENSIONS (w x h): 17,5 x 93 mm
SUPPORTED SYSTEMS: KNX
COLOUR: white (lacquered), black
WHITE KNX Motivity Ceiling: Motion Detection, Temperature Sensor, registers Brightness
BLACK KNX Motivity Ceiling: Motion Detection, Temperature Sensor
PROJECTION ZONE
The projection zone of the KNX Motivity Ceiling has an elliptical shape and detects up until a distance of 10m.
FUNCTIONS AVAILABLE:
Infrared movement detector.
Internal temperature sensor with correction.
Internal light sensor which can be corrected through calibration with a photometer. The light sensor of the White KNX Motivity Ceiling has a light read out value.
Master/Slave mode allows to control the action of the device programmed as master.
Up to four different output actions, which can be independently activated on certain conditions. Possible output actions: switching, dimming, recalling scenes, 1 or 2 Byte unsigned value, up/down, programmable logic ports etc.
Switch-off delay.
Possibility to control the ventilation.
Blocking object.
