The TX_44 design line is ideal for outdoor use thanks to its water-protected and sturdy design.
IP 44 protection against splash water
Materials: thermoplastic (ASA)
Shock-resistant, shatter-proof, UV-resistant, weather-resistant
Behaviour under chemical stress according to German standard DIN 68861, stress group 1b (for the options anthracite, aluminium)
Pure white (RAL 9010)
AREAS OF APPLICATION
Damp and dry rooms
Indoors and outdoors
Terraces and balconies
Kitchens and bathrooms
Staircases and public facilities
Gymnasiums, schools, and kindergartens
INSTALLATION OF GIRA TX44
Insert the flush-mounted wall box flush to the wall.
Install the flush-mounted insert with seal ring.
Position the frame and fasten it to the wall with dowels if necessary.
Attach the rocker or centre insert.
Clip on the cover plate.
INSTALLATION IN ACCORDANCE WITH IP 44
The Gira TX_44 design line includes a large number of functions which are IP 44 splash water-protected, e.g. switches, dimmers and automatic control switches, socket outlets with hinged cover and flush-mounted door stations for the door intercom system or an orientation light. In addition, a TX_44 adapter plate with a hinged cover can be used to integrate various devices for data connection technology and socket outlet variations and install them indoors and outdoors with IP44 splash water protection – from socket outlets with overvoltage protection and TAE socket outlets to network connection boxes.
INSTALLATION IN ACCORDANCE WITH IP 20
In dry rooms, electronic devices such as the electronic blind controller from Gira, pushbutton sensors, or the Info Display 2 can also be integrated into the Gira TX_44 design line using an intermediate frame without hinged cover. Plug and socket devices for connections with cable outlet as an angled socket outlet can alternatively be integrated via an intermediate frame with attachable cover cap. In both cases the installation conforms to the IP 20 standard.
